osmdata is an R package for accessing the data underlying OpenStreetMap (OSM), delivered via the Overpass API. (Other packages such as OpenStreetMap can be used to download raster tiles based on OSM data.) Overpass is a read-only API that extracts custom selected parts of OSM data. Data can be returned in a variety of formats, including as Simple Features (sf), Spatial (sp), or Silicate (sc) objects.

Installation

To install:

# Install from CRAN
install.packages("osmdata")

# Alternatively, install the development version
# install.packages("remotes")
remotes::install_github("ropensci/osmdata")

To load the package and check the version:

library(osmdata)
#> Data (c) OpenStreetMap contributors, ODbL 1.0. http://www.openstreetmap.org/copyright
packageVersion("osmdata")
#> [1] '0.1.1.4'

Usage

Overpass API queries can be built from a base query constructed with opq followed by add_osm_feature. The corresponding OSM objects are then downloaded and converted to R Simple Features (sf) objects with osmdata_sf() or to R Spatial (sp) objects with osmdata_sp(). For example,

x <- opq(bbox = c(-0.27, 51.47, -0.20, 51.50)) %>% # Chiswick Eyot in London, U.K.
    add_osm_feature(key = 'name', value = "Thames", value_exact = FALSE) %>%
    osmdata_sf()
x

#> Object of class 'osmdata' with:
#>                  $bbox : 51.47,-0.27,51.5,-0.2
#>         $overpass_call : The call submitted to the overpass API
#>                  $meta : metadata including timestamp and version numbers
#>            $osm_points : 'sf' Simple Features Collection with 24548 points
#>             $osm_lines : 'sf' Simple Features Collection with 2219 linestrings
#>          $osm_polygons : 'sf' Simple Features Collection with 33 polygons
#>        $osm_multilines : 'sf' Simple Features Collection with 6 multilinestrings
#>     $osm_multipolygons : 'sf' Simple Features Collection with 3 multipolygons

OSM data can also be downloaded in OSM XML format with osmdata_xml() and saved for use with other software.

osmdata_xml(q1, "data.osm")

Bounding Boxes

All osmdata queries begin with a bounding box defining the area of the query. The getbb() function can be used to extract bounding boxes for specified place names.

getbb ("astana kazakhstan")
#>        min      max
#> x 71.22193 71.78519
#> y 51.00068 51.35111

The next step is to convert that to an overpass query object with the opq() function:

q <- opq (getbb ("astana kazakhstan"))
q <- opq ("astana kazakhstan") # identical result

It is also possible to use bounding polygons rather than rectangular boxes:

b <- getbb ("bangalore", format_out = "polygon")
class (b); head (b [[1]])
#> [1] "matrix"
#> [1] 77.4601

Features

The next step is to define features of interest using the add_osm_feature() function. This function accepts key and value parameters specifying desired features in the OSM key-vale schema. Multiple add_osm_feature() calls may be combined as illustrated below, with the result being a logical AND operation, thus returning all amenities that are lebelled both as restaurants and also as pubs:

q <- opq ("portsmouth usa") %>%
    add_osm_feature(key = "amenity", value = "restaurant") %>%
    add_osm_feature(key = "amenity", value = "pub") # There are none of these

(Logical OR combinations are demonstrated below.) Negation can also be specified by pre-prending an exclamation mark so that the following requests all amenities that are NOT labelled as restaurants and that are not labelled as pubs:

q <- opq ("portsmouth usa") %>%
    add_osm_feature(key = "amenity", value = "!restaurant") %>%
    add_osm_feature(key = "amenity", value = "!pub") # There are a lot of these

Additional arguments allow for more refined matching, such as the following requrest for all pubs with “irish” in the name:

q <- opq ("washington dc") %>%
    add_osm_feature(key = "amenity", value = "pub") %>%
    add_osm_feature(key = "name", value = "irish",
                    value_exact = FALSE, match_case = FALSE)

See ?available_features and ?available_tags for further information.

Data Formats

An overpass query constructed with the opq() and add_osm_feature() functions is then sent to the overpass server to request data. These data may be returned in a variety of formats, currently including:

XML data (downloaded locally) via osmdata_xml();
Simple Features (sf) format via osmdata_sf();
R Spatial (sp) format via osmdata_sp();
Google Protocol Buffer (pbf; downloaded locally)) via osmdata_pbf(); and
Silicate (SC) format via osmdata_sc().

Additional Functionality

Logical OR combinations can be implemented with the package’s internal c method, so that the above example can be extended to all amenities that are either restaurants OR pubs with

pubs <- opq ("portsmouth usa") %>%
    add_osm_feature(key = "amenity", value = "pub") %>%
    osmdata_sf()
restaurants <- opq ("portsmouth usa") %>%
    add_osm_feature(key = "amenity", value = "restaurant") %>%
    osmdata_sf()
c (pubs, restaurants)

#> Object of class 'osmdata' with:
#>                  $bbox : 43.0135509,-70.8229994,43.0996118,-70.7279298
#>         $overpass_call : The call submitted to the overpass API
#>                  $meta : metadata including timestamp and version numbers
#>            $osm_points : 'sf' Simple Features Collection with 325 points
#>             $osm_lines : NULL
#>          $osm_polygons : 'sf' Simple Features Collection with 24 polygons
#>        $osm_multilines : NULL
#>     $osm_multipolygons : NULL

Data may also be trimmed to within a defined polygonal shape with the trim_osmdata() function. Full package functionality is described on the website

Citation

citation ("osmdata")
#>
#> To cite osmdata in publications use:
#>
#>   Mark Padgham, Bob Rudis, Robin Lovelace, Maëlle Salmon (2017).
#>   osmdata Journal of Open Source Software, 2(14). URL
#>   https://doi.org/10.21105/joss.00305
#>
#> A BibTeX entry for LaTeX users is
#>
#>   @Article{,
#>     title = {osmdata},
#>     author = {Mark Padgham and Bob Rudis and Robin Lovelace and Maëlle Salmon},
#>     journal = {The Journal of Open Source Software},
#>     year = {2017},
#>     volume = {2},
#>     number = {14},
#>     month = {jun},
#>     publisher = {The Open Journal},
#>     url = {https://doi.org/10.21105/joss.00305},
#>     doi = {10.21105/joss.00305},
#>   }
